| Details | |
|---|---|
| Product code | RBLHGG-5HPacD2HPnD-XL |
| Architecture | ARM 32bit |
| CPU | IPQ-4018 |
| CPU core count | ۴ |
| CPU nominal frequency | ۷۱۶ MHz |
| Switch chip model | IPQ4018 |
| Dimensions | Ø ۵۵۰ x 291 mm |
| RouterOS license | ۳ |
| Operating System | RouterOS |
| Size of RAM | ۲۵۶ MB |
| Storage size | ۱۶ MB |
| Storage type | FLASH |
| MTBF | Approximately 200’000 hours at 25C |
| Tested ambient temperature | -۴۰°C to 70°C |
| IPsec hardware acceleration | Yes |
| Suggested price | $۱۸۹.۰۰ |
| Details | |
|---|---|
| Number of DC inputs | ۱ (PoE-IN) |
| Max power consumption | ۱۸ W |
| Max power consumption without attachments | ۱۶ W |
| Cooling type | Passive |
| PoE in | ۸۰۲.3af/at |
| PoE in input Voltage | ۱۲-۵۷ V |
| Details | |
|---|---|
| Wireless 2.4 GHz Max data rate | ۳۰۰ Mbit/s |
| Wireless 2.4 GHz number of chains | ۲ |
| Wireless 2.4 GHz standards | ۸۰۲.11b/g/n |
| Antenna gain dBi for 2.4 GHz | ۱۸ |
| Wireless 2.4 GHz chip model | IPQ-4018 |
| Wireless 2.4 GHz generation | Wi-Fi 4 |
| Wireless 5 GHz Max data rate | ۸۶۷ Mbit/s |
| Wireless 5 GHz number of chains | ۲ |
| Wireless 5 GHz standards | ۸۰۲.11a/n/ac |
| Antenna gain dBi for 5 GHz | ۲۷ |
| Wireless 5 GHz chip model | IPQ-4018 |
| Wireless 5 GHz generation | Wi-Fi 5 |
| Details | |
|---|---|
| ۱۰/۱۰۰/۱۰۰۰ Ethernet ports | ۱ |
| Details | |
|---|---|
| SFP ports | ۱ |
| Details | |
|---|---|
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
| Mode button | Yes |
| Details | |
|---|---|
| Certification | CE, FCC, IC, EAC, ROHS |
| IP | IP54 |
| ۲.۴ GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 1MBit/s | ۲۹ | -۱۰۰ |
| 11MBit/s | ۲۹ | -۹۳ |
| 6MBit/s | ۳۱ | -۹۶ |
| 54MBit/s | ۲۷ | -۸۰ |
| MCS0 | ۳۱ | -۹۶ |
| MCS7 | ۲۶ | -۷۵ |
| ۵ GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 6MBit/s | ۳۰ | -۹۶ |
| 54MBit/s | ۲۶ | -۸۰ |
| MCS0 | ۳۰ | -۹۶ |
| MCS7 | ۲۵ | -۷۵ |
| MCS9 | ۲۳ | -۷۰ |
