●  ۳۲-Gbps switching fabric

●  Stack-forwarding rate of 38.7 mpps for 64-byte packets

●  Forwarding rate:6.5 mpps

●  ۱۲۸ MB DRAM and 16 MB Flash memory

●  Configurable up to 12,000 MAC addresses

●  Configurable up to 20,000 unicast routes

●  Configurable up to 1000 IGMP groups and multicast routes

●  Configurable maximum transmission unit (MTU) of up to 9000 bytes, with a maximum Ethernet frame size of 9018 bytes (jumbo frames) for bridging on Gigabit Ethernet ports, and up to 1546 bytes for bridging and routing on Fast Ethernet ports

●  10BASE-T ports: RJ-45 connectors, 2-pair Category 3 (Cat-3), 4, or 5 unshielded twisted-pair (UTP) cabling

•  100BASE-TX ports: RJ-45 connectors, 2-pair Cat-5 UTP cabling

•  100BASE-FX ports: MT-RJ connectors, 50/125 or 62.5/125 micron multimode fiber

•  1000BASE-T ports: RJ-45 connectors, 2-pair Cat-5 UTP cabling

•  1000BASE-T SFP-based ports: RJ-45 connectors, 2-pair Cat-5 UTP cabling

•  1000BASE-SX, -LX/LH, -ZX, and CWDM SFP-based ports: LC fiber connectors (single-mode, or multimode fiber)

•  10GBASE-ER XENPAK-based port (single-mode)

•  10GBASE-LR XENPAK-based port (single-mode)

•  Cisco StackWise stacking ports: copper-based Cisco StackWise cabling that is also compatible with the StackWise Plus technology in the Cisco Catalyst 3750-E Series Switches.

•  Management console port: RJ-45-to-DB9 cable for PC connections

●  Customers can provide power to a switch by using either the internal power supply or a redundant power system (Cisco RPS 2300 or the Cisco RPS 675). The connectors are located at the back of the switch.

● Internal power supply connector

●  The internal power supply is an autoranging unit.

●  The internal power supply supports input voltages between 100 and 240VAC.

●  Use the supplied AC power cord to connect the AC power connector to an AC power outlet.

●  Cisco RPS Connector

●  The connector offers connection for an optional Cisco RPS 2300 or RPS 675 that uses AC input and supplies DC output to the switch.

•  The connector automatically senses when the internal power supply of a connected device fails and provides power to the failed device, preventing loss of network traffic.

●  Only the Cisco RPS 2300 (model PWR-RPS2300) or the Cisco RPS 675 (PWR675-AC-RPS-N1=) should be attached to the redundant-power-supply receptacle.

●  Per-port status LEDs: link integrity, disabled, activity, speed, and full-duplex indications

●  System-status LEDs: system, RPS, and bandwidth-utilization indications

●  Operating temperature: 32 to 113ºF (0 to 45ºC)

●  Storage temperature: -13 to 158ºF (-25 to 70ºC)

●  Operating relative humidity: 10 to 85% (noncondensing)

●  Operating altitude: up to 10,000 ft (3049 m)

●  Storage altitude: up to 15,000 ft (4573 m)
