سوئیچ سیسکو N3K-C3164Q-40GE سوئیچی از نوع Nexus 3164Q با ۶۴پورت QSFP+ و 2RU است . سوئیچ Cisco Nexus 3164Q چگالی فوقالعاده بالا (ultra-high density) دارد و مصرف انرژی آن بهینه شده است که با سرعت ۱۰/40Gbps برای مرکز دیتا مناسب است. این سوئیچ فشرده (Compact ) با مدل دو رک (2RU) خود, سوئیچینگ لایه ۲ و لایه ۳ و wire-rate را در تمام ۶۴ پورت خود ارائه میدهد.
این دستگاه نسخه ارتقا یافته سیستم عامل Cisco NX-OS (که از سوئیچهای سری Nexus 9000 پشتیبانی میکند) را اجرا می کند. این دستگاه ویژگیهای جامعی به مشتری ارایه می دهد که مدیریت تصاویر را آسان می سازد همچنین به کمک خصوصیات خاص برنامهنویسی, سازمانها قادر خواهند شد که برنامههای کاربردی و روزمره شان را اجرا کرده, در عین حال برای نیازهای متغیر و رو به رشد آتی شرکت و همچنین برنامههای کاربردی (مانند بیگ دیتا، فضای ابری و مجازیسازی) آماده باشند.
| Product Code | N3K-C3164Q-40GE |
| Physical | ۲ RU fixed form-factor switch
۶۴ QSFP+ ports; each supports native 40 Gigabit Ethernet and 4 x 10 Gigabit Ethernet modes ۲ redundant power supplies ۳+۱ redundant fans Management, console, and USB flash-memory ports |
| Performance | ۵.۱۲ Tbps switching capacity
Forwarding rate up to 3.8 bpps Line-rate traffic throughput (both Layer 2 and 3) on all ports Configurable maximum transmission units (MTUs) of up to 9216 bytes (jumbo frames) |
| Physical dimensions (H x W x D) |
۳.۴۸ x 17.41 x 22.32in. (88.4 x 442 x 566 mm) |
| Weight | ۳۷ lb (16.8kg) |
| Product Code | N3K-C3164Q-40GE | N3K-C3264Q |
| Ports | ۶۴ QSFP+ ports; each supports native 40 Gigabit Ethernet and 4 x 10 Gigabit Ethernet modes | ۶۴ QSFP+ ports; each supports native 40 Gigabit Ethernet |
| Physical dimensions (H x W x D) | ۳.۴۸ x 17.41 x 22.32in. (88.4 x 442 x 566 mm) | ۳.۳۹ x 17.41 x 22.32 in. (88.4 x 442 x 566 mm) |
| Weight | ۳۷ lb (16.8kg) | ۳۲.۸ lb (14.9 kg) |

N3K-C3164Q-40GE Specification |
||
| Physical | · ۲ RU fixed form-factor switch
· ۶۴ QSFP+ ports; each supports native 40 Gigabit Ethernet and 4 x 10 Gigabit Ethernet modes · ۲ redundant power supplies · ۳+۱ redundant fans · Management, console, and USB flash-memory ports |
|
| Performance | · ۵.۱۲ Tbps switching capacity
· Forwarding rate up to 3.8 bpps · Line-rate traffic throughput (both Layer 2 and 3) on all ports · Configurable maximum transmission units (MTUs) of up to 9216 bytes (jumbo frames) |
|
| Hardware tables and scalability | Number of VLANS | MSTP: 4096 |
| Number of spanning-tree instances | MSTP: 64
RPVST+: 507 |
|
| Number of access control list (ACL) entries | ۴۰۰۰ to 16000 ingress
۱۰۰۰ to 4000 egress |
|
| Routing table | Maximum number of longest prefix match (LPM) routes 128,000
Maximum number of IP host entries 120,000 Maximum number of MAC address entries 96,000 |
|
| Number of EtherChannels | ۲۵۶ | |
| Number of ports per EtherChannel | ۳۲ | |
| Buffer size | ۴۸ MB shared | |
| System memory | ۱۶ GB | |
| Power | Frequency | ۵۰ to 60 Hz |
| Power supply types | AC | |
| Typical operating power | ۸۰۳ Watts (W) with SR4 optics at 100% load; 2 PSUs | |
| Maximum power | ۱۱۰۰ Watts (W) | |
| AC PSUs
· Input voltage · Frequency · Efficiency |
· ۲۰۰ to 240 VAC · ۵۰ to 60 Hz · ۹۳% at 220V |
|
| Typical heat dissipation | ۲۷۳۹ BTU/hr (with SR4 optics at 100% load) | |
| Maximum heat dissipation | ۳۷۵۳ BTU/hr | |
| Cooling | Port-side intake and port-side exhaust options
Port-side intake: Yes Port-side exhaust: Post FCS |
|
| Dimensions | · Dimensions (height x width x depth) | ۳.۴۸ x 17.41 x 22.32in. (88.4 x 442 x 566 mm) |
| Environment | Weight | ۳۷ lb (16.8kg) |
| Operating temperature | ۳۲ to 104°F (0 to 40°C) | |
| Storage temperature | -۴۰ to 158°F (-40 to 70°C) | |
| Operating relative humidity | · ۱۰ to 85% noncondensing
· Up to 5 days at maximum (85%) humidity Recommend ASHRAE data center environment |
|
| Storage relative humidity | ۵% to 95% noncondensing | |
| Altitude | ۰ to 10,000 ft (0 to 3000m) | |
